CFUE4M-01
4 Module Enclosure Empty, comes with Cables and Busbar
No main switch
IP20
4 module
All Metal Construction
DIN Rail
Comes with Neutral cable
Backed out and retained terminal screws
Tripod fixing points
Easy Installation
Unpopulated
| Front Plate Material | Steel 1.0mm - ST16 |
| General Colour | White |
| Fixing Screws Supplied | No |
| Modules | 4 |
| Number of Cable Entries | 9 |
| Captive Terminal Screws | Yes |
| Backed-out Terminal Screws | Yes |
| Cable Entry Type | Knockout |
| Details per face (Size/number) | 5 - 2 x 20mm 1 x 32mm (Top/Bott) 1 x 32mm Side 1 x 37 x 67mm (Base) |
| Number Of Wall Fixing Positions | 5 |
| Fitted Lock | No |
| Installation Method(s) | Surface |
| Spirit Level | Yes |
| Terminal Type | Screw |
| Ways | 4 |
| Number of Knockouts | 6 |
| Mounting Type | Surface |
| IP Rating | IP20 |
| Terminal Screw Type | Combi |
| Terminal Torque (Nm) | Earth/Neutral Terminals 2.0Nm |
| Rated Sensitivity (mA) | N/A |
| RCD Mechanism Type | N/A |
| Trip Speed (mS) | N/A |
| Max Load (A) | 0 |
| MCB's | 0 |
| Standard(s) | BS EN 60898-1:2019;BS EN 60947-3:2009+A2:2015;BS EN 61008-1:2012+A12:2017;BS EN 61009-1:2012+A12:2016;BS EN 61439-1:2011;BS EN 61439-3:2012;EN 60898-1:2019;EN 60947-3:2009+A2:2015;EN 61008-1:2012+A12:2017;EN 61009-1:2012+A12:2016;EN 61439-1:2011;EN 61439-3:2012 |
| Frequency (Hz) | 50 |
| Warranty (years) | 10 |
