CUR6330BN-02
Bidirectional 63A RCD Type B double pole 30mA 2 module
30mA Earth Leakage Protection
Type A
Type B RCD
2 Module
Bidirectional
DIN-Rail Mounted
63A Rated
Double Pole
| General Colour | Light Grey |
| Module Width (mm) | 36 |
| Endurance Operations - Electrical | 4000 |
| Endurance Operations - Mechanical | 10000 |
| Rated Sensitivity (mA) | 30mA |
| RCD Mechanism Type | Electro/Mechanical |
| Trip Speed (mS) | <0.1s |
| RCD Type | Type B |
| Devices | RCD |
| Operating Voltage (V) | 230 |
| Current Rating (A) | 63 |
| Operating Temperature (°C) | -25 to +40 |
| Rated Trip Current (mA) | 30mA |
| Terminal Capacity (# x mm²) | 1 x 35 |
| Frequency (Hz) | 50 |
