RBS12C-01
BG Grid 20A Switch Module 2 Way, Single Pole, Centre Off, Brushed Steel
Easy to install, supplied with fixing screws and installation instructions
2 way switching allows for a second switch position in a circuit
Centre off position for dual circuit control
Captive backed out terminal screws for fast installation
Module to be installed with Grid frame and plate
Single pole
| General Colour | Brushed Steel |
| Captive Terminal Screws | Yes |
| Backed-out Terminal Screws | Yes |
| Minimum Box Depth (mm) | 25 |
| Terminal Capacity (N x mm²) | 4 x 1.0, 4 x 2.5, 2 x 2.5, 1 x 4 |
| Anti-fingerprint Lacquer | No |
| Anti-microbial Property | No |
| Fixing Screws Supplied | N/A |
| Terminal Arrangement | N/A |
| Terminals with Colour Coding Print | No |
| Number of Switches | 1 |
| Screw Caps | N/A |
| Switch Style Type | Rocker |
| Switch Type (Ways & Poles) | Two Way |
| Switch Location Position | Wall |
| IP Rating | IP20 |
| Operating Voltage (V) | 220-240 |
| Switch State | On/Off |
| Warranty (years) | 25 |
