Introducing BG Smart!

Smart Power Sockets & Adaptor

An affordable smart home integration that is quick and simple to install and setup. Controlled using voice command, touch or smartphone. Connects directly, without the need to use a home hub. Retrofittable to suit any 25mm back box.

800 Series
Socket Range

900 Series
Socket Range

Plug-in
Adaptor
Find out more
Get it on Google Play

Compatible with:

Specifications

AHC/U

Standard(s)

Low Voltage Directive 2014/35/EU

BS1363-2 : 2016 + A1:2018

EN 60669-2-1 : 2004 + A1:2009 + A12:2010

WEEE Directive

Yes

RoHS Directive

Yes

CE

Yes

Rating

13 Amp

240 Volts

3120 Watts

50/60 Hz

Contact Gap

3.0mm minimum

Switch Type

Single Pole

Stand-by Power

<0.3W

Working Condition Temp

-20 - +85°C (For WiFi module)

Connection Protocol

WiFi (Fast Con)

822/HC + 922/HC

Standard(s)

Low Voltage Directive 2014/35/EU

BS1363-2 : 2016 + A1:2018

EN 60669-2-1 : 2004 + A1:2009 + A12:2010

WEEE Directive

Yes

RoHS Directive

Yes

CE

Yes

Rating

13 Amp

240 Volts

3120 Watts

50/60 Hz

Contact Gap

3.0mm minimum

Switch Type

Single Pole

Terminal Capacity - L & N

3 x 2.5mm2, 3 x 4.0mm2 & 2 x 6.0mm2

Mounting Box Depth (Min)

25mm

Fixing Centres

120.6mm

Stand-by Power

<0.3W

Working Condition Temp

-20 - +85°C (For WiFi module)

Connection Protocol

WiFi (Fast Con)

Wireless Specifications

Wireless Frequency

2.4GHz

Wireless IEEE Standards

IEEE802.11b/g/n

Security Type

WAP/WAP2

Security Mechanism

Encryption standard :

Open/WEP-Open/WPA/WPA2

Encryption algorithm :

WEP64/WEP128/TKIP/AES
