FBSKYCSG-01
BG Screwless Flat plate Brushed Steel, 16A Key Card Switch, Grey Insert
16A Rated
Easy to install, supplied with fixing screws and installation instructions
Power to the room will active when a key card inserted so the room is only powered when occupied
30 second power-off delay prevents users being plunged in to darkness when leaving
Locator LED ideal for night operation
Colour coded in-line terminals for easy identification
Captive screws prevent screw loss
Screwless front plate clips on and off easily and has a sleek flat profile
Supplied as kit of Euro module components
Minimum mounting box depth 47mm
| General Colour | Brushed Steel |
| Captive Terminal Screws | Yes |
| Backed-out Terminal Screws | Yes |
| Minimum Box Depth (mm) | 35 |
| Terminal Capacity (N x mm²) | 4 x 1.0, 4 x 2.5, 2 x 2.5, 1 x 4 |
| Anti-fingerprint Lacquer | Yes |
| Anti-microbial Property | No |
| Fixing Screws Supplied | Yes |
| Terminal Arrangement | N/A |
| Terminals with Colour Coding Print | No |
| Number of Switches | 0 |
| Screw Caps | No |
| Switch Style Type | Key |
| Switch Type (Ways & Poles) | Single Pole |
| Switch Location Position | Wall |
| Fixing Centres (mm) | W-60.3 |
| IP Rating | IP20 |
| Operating Voltage (V) | 220-240 |
| Switch State | On/Off |
| Warranty (years) | 25 |
