CUR100100TDA-01
BG Double Pole RCD 100mA Time Delayed Type A 100A
For Use with BG Fortress consumer unitss
Positive contact status indication
Device capable of being locked in 'ON' or 'OFF' position using a device lock
Type A
Double Pole
100mA
Manual test button
2 Module
| General Colour | Light Grey |
| Rated Sensitivity (mA) | 100mA Delayed |
| RCD Mechanism Type | Electro/Mechanical |
| Trip Speed (mS) | <0.1s |
| Operating Voltage (V) | 240 |
| Current Rating (A) | 100 |
| Operating Temperature (C) | -5°C to +40°C |
| Standard(s) | BS EN 61008-2-1:1995;BS EN 61543:1996;EN 61008-2-1:1995;EN 61543:1996 |
| Frequency (Hz) | 50 |
| Warranty (years) | 10 |
