CFEV5A-02
Sync Energy electric vehicle populated grey enclosure 5 module IP65 with 40A 30mA RCD, 1 x 40A MCB and 1 x Type 2 surge protection device
Populated
Supplied with Type 2 Surge Protection Device
Supplied with 40A RCD
5 Module Capacity
30mA Earth Leakage Protection
Type A
40A MCB
IP65 Weatherproof
Compliant with EV Charging Requirements
Anthracite Grey Enclosure
| General Colour | Anthracite Grey |
| Fixing Screws Supplied | No |
| Modules | 5 |
| Number of Cable Entries | 11 |
| Captive Terminal Screws | Yes |
| Backed-out Terminal Screws | Yes |
| Cable Entry Type | Knockout |
| Details per face (Size/number) | 6 - 3 x M20-32 2 x M20-32 (side) 1 x M20-32 (Base) |
| Number Of Wall Fixing Positions | 4 |
| Fitted Lock | No |
| Installation Method(s) | Surface |
| Spirit Level | No |
| Ways | 2 |
| Number of Knockouts | 11 |
| Mounting Type | Surface |
| IP Rating | IP65 |
| Terminal Screw Type | Combi |
| Rated Sensitivity (mA) | 30mA |
| RCD Mechanism Type | Electro/Mechanical |
| Trip Speed (mS) | <0.1s |
| Operating Voltage (V) | 230 |
| Current Rating (A) | 40 |
| Max Load (A) | 40 |
| MCB's | 1 |
| Operating Temperature (°C) | -25 to +40 |
| Frequency (Hz) | 50 |
